508DT

Thermal Forming Machine

Applications

Forming Area

482 × 432 mm (19″ × 17″)

Max Sheet Size

508 × 457 mm (20″ × 18″)

Max Depth of Draw

160 mm (6.3″)

Max Material Thickness

6 mm (0.25″)

Heating

Quartz, 4 controllable zones

Controls

7″ touchscreen, 20-program memory

Vacuum Pump

Built-in (no external air required)

Power

208–240V, 13A, single phase

Dimensions

890 × 970 × 790 mm

Weight

105 kg
