508FS

Thermal Forming Machine

Applications

Forming Area

482 × 432 mm (19″ × 17″)

Max Sheet Size

508 × 457 mm (20″ × 18″)

Max Depth of Draw

290 mm (11.4″)

Max Material Thickness

6 mm (0.25″)

Heating

4 independently controllable quartz heating zones

Control Interface

3.8" mono HMI with 20-program memory

Vacuum Pump

Dry rotary vane pump, 10 m³/h flow rate

Power Requirements

208–240V, 20A

Dimensions

757 × 1,140 × 1,474 mm

Weight

125 kg
