NEW

686

Thermal Forming Machine

Chat on WhatsApp

Applications

SPECIFICATIONS

Forming Area

646 × 620 mm (25.5″ × 24.5″)

Max Sheet Size

686 × 660 mm (27″ × 26″)

Max Depth of Draw

320 mm (12.6″)

Max Material Thickness

6 mm (0.25″)

Heating

Quartz strip, 6 independently controllable zones

Controls

5″ color touchscreen PLC; 20-program memory

Features

Auto-leveling, pre-stretch, vacuum gauge & flow regulator

Table

Pneumatic power lift for easy mold loading

Vacuum Pump

Dry rotary vane – 16 m³/h (11 SCFM)

Power

Single-phase 208–240 V (40 A); ~8 kW

Air Requirement

~6 bar (87 psi)

Dimensions

~960 × 1,165 × 1,932 mm

Weight

~260 kg

REQUEST A QUOTATION
