Forming Area
280 × 230 mm (11×9″)
Max Sheet Size
300 × 250 mm (12×10″); draw depth up to 130–140 mm
Material Thickness
Up to 4 mm
Heating
Single-zone quartz strip heater; fast and efficient
Vacuum Pump
Built-in diaphragm pump (approx. 1.7 SCFM / 2.4 m³/h) with vacuum gauge and release mode
Controls
Digital timer with audible alarm; safety interlock prevents raising while heater is forward
Power
208–240 V, 13 A single-phase; around 1.1 kW consumption
Size & Weight
440 × 425 × 835 mm; 33 kg
Features
Stainless steel clamp frame, vacuum gauge, audible timer, safety interlock, optional small trolley
