XPJ-1682UR

NEW

XPJ-1682UR

UV LED Roll-to-Roll Printer

64” (162 cm) UV LED piezo drop-on-demand printer
6 colour channels : C, M, Y, K, Wh, Va
Two 8-channel monoblock 1440 nozzle print heads
Two 4” (101.6 mm) UV lamps
Speeds up to 26,5 m²/h
Prints up to 5 layers without media pull back
High user assistance - Multiple automated calibrations
Environmentally responsible inks:no CMR category 1 ingredients, SVHC1 free*

Mutoh’s XpertJet 1682UR is a 64” (162 cm) high-productivity UV LED printer built on Mutoh’s award-winning latest-generation XpertJet print platform. The printer is powered by Mutoh’s US61 series C, M, Y, K, White and Varnish SVHC1 free inks.

Applications

Signage & Displays
Industrial & Specialty Printing
Customization & Branding

SPECIFICATIONS

Print Width:

Up to 1,625 mm (64 inches)

Print Heads:

2 staggered AccuFine 1600 piezo heads

Resolution:

Up to 1,440 x 1,440 dpi

Ink Type:

Mutoh US61 UV-LED ink (CMYK, White, Varnish)

Ink Capacity:

800 ml bags

Media Width:

500 mm to 1,625 mm

Media Thickness:

Up to 1.3 mm (adjustable head height)

Print Speeds:

Up to 27.3 m²/h (Draft mode)

Connectivity:

Gigabit Ethernet (1000BASE-T)

Power Consumption:

950W (operating), 21W (sleep mode)

Dimensions (W x D x H):

2,770 x 895 x 1,504 mm

Weight:

181 kg (printer body: 149 kg, stand: 32 kg)
